MAX POWER MC Series
Bring 7-60KW DC fast charging anywhere. At just 20kg (7KW model), its IP43-rated chassis survives drops, dust, and -25°C blizzards. Features isolated cooling ducts, cloud platform control, and plug-and-charge. Deploy power in minutes.
OEM / ODM
Mobile and portable
Rich Configuration
Safety protection
Mobile DC Charging Station
MC series
Engineered for extreme mobility, the MC Series packs industrial power into ultra-compact frames (450×150×310mm to 650×200×445mm). With 95% efficiency and >99% power factor, it delivers 60KW output at 200A—equivalent to 400km range per hour.
Specification of MC Series
| Product Parameters | |||||
|---|---|---|---|---|---|
| Product Model | MC07750 | MC201K | MC301K | MC401K | MC601K |
| Rating | 7KW | 20KW | 30KW | 40KW | 60KW |
| Output voltage | 200-750V | 200-1000V | |||
| Input voltage | 90-265V | 260-475V | |||
| Input Current | 32A | 30A | 45A | 60A | 90A |
| Output Current | 20A | 50A | 100A | 120A | 200A |
| Input wiring | L+N+PE | 3P+N+PE | |||
| Frequency | 50-60HZ | ||||
| Power factor | >99%(Rated voltage& full power) | ||||
| Work efficiency | 95% | ||||
| User interface | Digital tube | 4.3-inch touch Display | |||
| Sizes (mm) | 450*150*310 | 580*180*430 | 650*200*445 | ||
| Weights | 20KG | 28KG | 44KG | 60KG | |
| Ancillary sources | 12V(24V Optional) | ||||
| Operating temperature | -25℃-+50℃（DeRating above 50℃, with heater for very cold areas） | ||||
| Height above sea level | 2000M | ||||
| IP Rating | IP43 | ||||
| crashworthiness Rating | IK8+ | ||||
| Input line length | 5M(Customization acceptable) | ||||
| Charge Gun Cable Length | 3M(Customization acceptable) | ||||
| Applicable standards | GB/T18487/EN62196/EN61851-23,JEVSG 105/CHAdeMO | ||||
| Communication protocols | GB/T27930/CHAdeMO2.0/DIN70121,ISO 15118 | ||||
Patented Designs
- Small size, light weight, movable, charging anytime and anywhere;
- Unique air duct design, hot and cold air duct isolation, enhance the efficiency of heat transfer, product performance is more stable; easy to maintain.
Safe and secure
- IP43 protection grade + IK8 anti-collision grade; it can be moisture-proof, water-proof, mold-proof, dust-proof, flame retardant and so on;
- At the same time with over-voltage, overload, short circuit, leakage, battery anti-reverse and other protection functions.
Rich Configuration
- Supports OCPP, DLB (Dynamic Load Balancing), RFID, 4G, LAN, WIFI, Bluetooth, Reservation, C10Password, Cloud Platform Charging and more.
